Model No. |
TL600C |
TL660C |
TL800C |
|
Item No. |
|
|
|
|
Specifications |
|||
|
Distance between centers |
1000/1500/2000/3000 mm |
||
|
Bed width |
400 mm |
||
|
Swing over bed |
600 mm |
660 mm |
|
|
Swing over gap |
800 mm |
860 mm |
|
|
Swing over cross slide |
400 mm |
460 mm |
|
|
Spindle nose |
ISO-C11 or D11 |
||
|
Spindle bore |
103mm |
||
|
Range of spindle speeds |
forward rotation 9-1275 rpm/18 reverse rotating 16-816 rpm/6 |
||
|
Range of cross feeds |
0.036-2.033 mm/r 72 kinds |
||
|
Range of longitudinal feeds |
0.073-4.066mm/r 72 kinds |
||
|
Range of inch threads |
56-1/4 T.P.I/72 |
||
|
Range of metric threads |
0.5-112 mm/72 |
||
|
Range of moduler threads |
0.5-7 mm/36 |
||
|
Range of diametrical threads |
56-4 D.P/36 |
||
|
Top slide travel |
110 mm |
||
|
Cross slide travel |
325 mm |
||
|
Tailstock quill travel |
150 mm |
||
|
Tailstock quill diameter |
90 mm |
||
|
Tailstock quill taper |
MT6 |
||
|
Main motor |
7.5kw |
7.5kw |
11kw |
|
Rapid feed motor |
0.25 kw |
||
|
Coolant pump motor |
90W |
||
|
Packing size |
2820/3320/3820/4820x1300x1650 mm |
||
|
Net weight |
2900/3150/3400/3800kg 3500/3750/4050/4450 kg |
||
|
Standard Accessories |
Optional Accessories |
|
3-jaw chuck (325mm) |
Quick change tool post |
|
4-jaw chuck (400mm) |
Turning tools |
|
Face plate |
Leadscrew cover |
|
Steady rest |
Chuck guard |
|
Follow rest |
Tool post cover |
|
Splash guard |
Digital readout system |
|
Stand & oil tray |
Taper turning attachment |
|
Halogen work lamp |
Rapid moving attachment |
|
Toolbox & tools |
|
|
Coolant system |
|
|
Foot brake |
|
