Model No. |
VLK5225 |
VLK5240 |
VLK5250Q |
|
Item No. |
|
|
|
|
Specifications |
|||
|
Max. turning diameter |
2500 mm |
4000 mm |
5000 mm |
|
Table diameter |
2250 mm |
2830 mm |
3600 mm |
|
Max. height of workpiece |
1600 mm |
2000 mm |
2000 mm |
|
Max. weight of workpiece |
10/20 T |
10/20/32 T |
32 T |
|
Max. cutting force of right head |
29.4 KN |
29.4 KN |
40 KN |
|
Max. cutting force of left head |
26.46 KN |
26.46 KN |
35 KN |
|
Total cutting farce |
55.86 KN |
55.86 KN |
63 KN |
|
Max. torque of table |
55.86 KN.M |
55.86 KN.M |
63 KN.M |
|
Range of table speed |
2-63 r/min |
2-63 r/min | 1-52 r/min |
|
Table speed steps |
16 / stepless |
16 / stepless | 18 / stepless |
|
Range of feed rates |
0.1-1000(stepless) mm/min |
||
|
Travel of cross rail |
1250 mm |
1650 mm | 1800 mm |
|
Horizontal travel of heads |
1400 mm |
2150 mm | - 50-2735 mm |
|
Vertical travel of heads |
1250 mm |
||
|
Elevating speed of cross rail |
350 mm/min |
||
|
Rapid traverse of rail heads |
2000 mm/min |
2000 mm/min | 3000 mm/min |
|
Power of main motor |
55 kw |
||
|
Overall dimensions |
5180*4560*4680 mm |
6780*4850*5080 mm | 8200*5880*6300 mm |
|
Machine weight(approx) |
32 T |
38 T | 55 T |
|
|
|
||
|
|
|
|
|
