Model No.

RD3208

RD3210

    Item No.

　Specifications

　Max. drilling capacity

Φ32 mm

Φ32 mm

　Distance from spindle axis to column

320 ~ 820 mm

320 ~ 1000 mm

　Diameter of column

200 mm

240 mm

　Spindle taper

MT4

MT4

　Spindle stroke

240 mm

280 mm

　Step of spindle speeds

6

16

　Range of spindle speeds

75 ~ 1220 rpm

32 ~ 2500 rpm

　Step of spindle feeds

3

8

　Range of spindle feeds

0.1 ~ 0.25 mm/rev.

0.1 ~ 1.25 mm/rev.

　Distance from spindle nose to base

120 ~ 860 mm

220 ~ 1000 mm

　Dimension of worktable

400 x 400 x 350 mm

600 x 450 x 450 mm

　Base size

1370 x 700 x 160mm

1710 x 800 x 160mm

　Main Motor

1.5 kw

2.2 kw

　Overall size

1407 x 720 x 1885 mm

1760 x 800 x 2050 mm

　Packing size (cm)

1550 x 770 x 2100 mm

1870 x 970 x 2100 mm

　Net weight

1200 kg

1600 kg
