FEATURE:
● V-way bed is hardened and precision ground.
●Spindle is supported by precision tapered roller bearing.
●Gear head enables to change speeds quickly.
●Power longitudinal feed allows threading.
●Adjustable gibs for slideways.
●Tailstock can be offset for turning tapers.
●Tolerance test certificate, test flow chart included.
|
Model No. |
TN210V-G |
|
Item No. |
|
|
Specifications |
|
|
Distance between centers |
400 mm |
|
Swing over bed |
210 mm |
|
Swing over cross slide |
110 mm |
|
Width of bed |
100 mm |
|
Taper of spindle bore |
MT3 |
|
Spindle bore |
21 mm |
|
Number of spindle speeds |
Variable speed |
|
Range of spindle speeds |
50-2500 rpm |
|
Range of longitudinal feeds |
0.10-0.20 mm |
|
Range of inch threads |
8-44T. P. I |
|
Range of metric threads |
0.5-3 mm |
|
Top slide travel |
55 mm |
|
Cross slide travel |
75 mm |
|
Tailstock quill travel |
60 mm |
|
Taper of tailstock quill |
MT2 |
|
Motor |
450W |
|
Packing size |
900x480x470 mm |
|
Net weight |
75 kg |
|
Standard Accessories |
Optional Accessories |
|
3-jaw Chuck (100mm) |
4-jaw chuck (100mm) |
|
Splash guard |
Backplate |
|
Chip tray |
Follow rest |
|
Toolbox & tools |
Steady rest |
|
Speed DRO |
Face plate (175mm) |
|
|
Threading dial |
|
|
Stand |
