Model No. |
M7140A |
M7140AX1600 |
|
|
Item No. |
|
|
|
|
Specifications |
|
|
|
|
Table size (mm) |
400x1000 mm |
400x1600 mm |
|
|
Max. machining dimension (mm) |
400x1000 mm |
400x1600 mm |
|
|
Distance from spindle to table |
600 mm |
||
|
Longitudinal feed speed of worktable |
3-25 m/min. |
||
|
T-slot |
3x18 mm |
||
|
Wheelhead |
Continuous feed speed |
0.5-4.5 m/min. |
|
|
Intermittent feed speed |
3-30 mm/t |
||
|
Handwheel feed |
0.02 mm/gra |
||
|
Vertical moving |
Rapid speed |
400 mm/min. |
|
|
Handwheel feed |
0.005 mm/gra |
||
|
Wheel head |
Power |
7.5 kw |
|
|
Rotation speed |
1440 rpm |
||
|
Total power |
11 kw |
13.5 kw |
|
|
Max loading of able (with chuck) Kg |
620 kg |
1000 kg |
|
|
Chuck size (mm) |
400x1000x1 mm |
400x800x2 mm |
|
|
Wheel size (ODxWxlD) (mm) |
400x40x127 mm |
400x40x127 mm |
|
|
Machine dimension (cm) |
311x182x223 cm |
494x182x223 cm |
|
|
Package dimension (cm) |
320x220x233 cm |
500x220x233 cm |
|
|
Net weight (Kg) |
5010 kg |
6510 kg |
|
