Model No. |
D40A |
D50A |
|
Item No. |
|
|
|
Specifications |
||
|
Max. drilling capacity |
Φ40 mm |
Φ50 mm |
|
Max. tapping capacity |
M27 |
M30 |
|
Spindle taper |
MT4 |
MT4 or MT5 |
|
Spindle stroke |
180 mm |
240 mm |
|
Step of spindle speeds |
12 |
|
|
Range of spindle speeds |
42 ~ 2050 rpm |
|
|
Spindle feeds |
0.07/0.15/0.26/0.40 mm/rev. |
|
|
Diameter of column |
160 mm |
180 mm |
|
Distance from spindle to column |
360 mm |
|
|
Distance from spindle nose to table |
600 mm |
|
|
Distance from spindle end to base |
1180 mm |
1160 mm |
|
Table size |
580 x 450 mm |
|
|
Table travel |
550 mm |
|
|
Base size |
820 x 550 mm |
|
|
Main Motor |
2.2/2.8 kw |
|
|
Coolant motor |
90 w |
|
|
Packing size |
700 x 1150 x 2150mm |
700 x 1150 x 2300mm |
|
Net weight |
680 kg |
750 kg |
