Model No. |
DPX5125A |
DPX5132A |
|
Item No. |
|
|
|
Specifications |
||
|
Motor power |
1100 W |
1100 W |
|
Chuck |
20 mm |
20 mm |
|
Spindle stroke |
120 mm |
120 mm |
|
Spindle taper |
MT3 |
MT4 |
|
Speed steps |
12 |
12 |
|
Speed 50Hz |
150-2450 rpm/ 180-2940 rpm |
150-2450 rpm/ 180-2940 rpm |
|
Swing |
452 mm |
510 mm |
|
Table size |
350x350 mm |
470x420 mm |
|
Base size |
470x360 mm |
580x430 mm |
|
Column |
Φ92 mm |
Φ92 mm |
|
Total height |
1680 mm |
1720 mm |
|
Weight |
108/98 kg (110/108 kg) |
128/118 kg (148/138 kg) |
|
Packing size |
1430x660x320 mm |
1430x660x320 mm |
|
Loading Qty in 20” CTN |
90pcs |
90pcs |
|
Optional |
152mm 6” VICE |
203mm 8” VICE |
