Model No. |
DP5125A |
DP5132 |
DP5132A |
|
Item No. |
ZJ5125 |
ZJQ5132 |
ZJ5132 |
|
Specifications |
|||
|
Motor power |
1.1 kw |
1.1 kw |
1.1 Kw |
|
Chuck |
20 mm |
20 mm |
20 mm |
|
Spindle stroke |
120 mm |
120 mm |
120 mm |
|
Spindle taper |
MT3 |
MT4 |
MT4 |
|
Speed steps |
12 |
12 |
12 |
|
Speed 50/60Hz |
150-2450 rpm/ 180-2940 rpm |
150-2450 rpm/ 180-2940 rpm |
150-2450 rpm/ 180-2940 rpm |
|
Swing |
452 mm |
452 mm |
510 mm |
|
Table size |
350x350 mm |
360x360 mm |
470x420 mm |
|
Base size |
470x360 mm |
470x360 mm |
580x430 mm |
|
Column |
Φ92 mm |
Φ92 mm |
Φ92 mm |
|
Total height |
1700 mm |
1710 mm |
1730 mm |
|
Weight |
100 kg |
110 kg |
120 kg |
|
Packing size |
1430x660x330 mm |
1430x660x330 mm |
1430x660x330 mm |
|
Loading Qty in 20” CTN |
90pcs |
90pcs |
90pcs |
